Centrifugal Mixed Flow Propeller Submersible Pump Water For Irrigation Dock Shipyard

Mixed flow submersible pump, the motor driving the pump is dry type fully enclosed submersible three-phase asynchronous motor.

The pump and motor shaft are integrated.Can be long - term underwater operation, with a series of traditional units incomparable advantages.

Because the pump and motor together ,Can Diving into the water at the same time, there is no need to carry out power consumption and time-consuming assembly process at the installation site, which is convenient and fast for on-site installation.

Mixed flow water submersible pump:

(Notice: flow rate, head meters, power, material, ODM OEM is available)

Cable: it is a mine cable with thick insulation layer and rubber sheath, which is not easy to be damaged in use.

Connection box: the connection box is explosion-proof sealing structure, even if there is water in the connection box due to special reasons, it will not enter the motor cavity, so the sealing is more reliable..

Bearing : SKF Bearing

Motor: F class insulation ,Protection level: IP68,Equipped with dew-proof device...

Protection monitoring system:

1. Motor overheating protection (winding), using PTC components.

2. Water inlet protection in motor cavity.

3. Water inlet protection of oil chamber.

4. Bearing over temperature protection.

Cooling system: pump water out of the motor housing to effectively cooling the motor.

Mechanical seal: Double or triple mechanical seal, can effectively prevent water infiltration into the motor, according to the pump working medium, choose different materials, longer service life.

Impeller: The use of optimized design of the axial flow adjustable blade, a wide range of use, to meet the needs of different customers. Stainless steel material, long time corrosion resistant.

Zhengzhou Shenlong Pump Industry CO.,Ltd have been exported to more than 70 countries and regions, such as Southeast Asia, Europe, Africa, South America and Oceania and so on. It is the leader in the submersible pump industry in domestic, always stressing on quality and credibility. The company has participated in national standards and plays an important role in amending the national standards, such as CE, ABS.

Why choose us?

1. Specialized production Manufacturer for Water Pump

2. Focus on technological innovation, Over Industry leading level

3. Good experience at Domestic and oversea market

4. Carefully paint for Good appearance

5. Years of International service standards, Engineer one-to-one service

    Zhengzhou Shenlong Pump Industry CO.,Ltd, a professional reputable ODM OEM water pump manufacturer in China since 1996, recognized by CE and ISO, ABS, SGS, BV.

  Main products: Electric Submersible Pump for pumping clean water, hot water and sea water with bronze, SS304, SS316, SS316L, Dupex stainless/SS904L; Mine Submersible Pump/Submersible Motor/Sewage Submersible Pump/Slurry Submersible Pump/Fountain Submersible Pump/Axail Flow Submersible Pump/Surface Centrifugal Water Pump. Related business: kinds of water pipes, cables, control panels, inverter and other pump spare parts.

   Over 70 countries’ customers are enjoying our pumps and service. Our pumps are widely used in fields, such as seawater aquaculture & desalination, offshore, jack-up, floating dock, shipyard, irrigation, wastewater treatment, fountain projects. We are seeking for local water pump service business and dealer who is professional in water pumps. Welcome to join us.

    Zhengzhou Shenlong Pump Industry CO.,Ltd has three complete casting lines, including Expendable casting process, wax casting mold, coated sand, it can meets the different requirements on the dimensional accuracy of casting. The wax casting mold line, special for stainless steel material, was finished in the thermostatic workshop to guarantee the casting accuracy, meanwhile, shorten the whole production time.

  More than 85 sets production machine, includes grinding machine, CNC, lathe, Milling, High speed punch press machine, testing machine, etc., with sufficient spare parts stock to guarantee the production capacity 11,000 sets per month. From material purchase, metalworking, impeller dynamic balance, motor winding, insulation and pump assembling, passed more than 27 inspection processes, to ensure the quality meet a criterion.
