250KW 280KW 315KW Sewage Pump For Mine Or Hospital

250KW 280KW 315KW Sewage Pump For Mine Or Hospital Product use:

WQ series sewage submersible pumps are mainly used in municipal engineering, industrial buildings, hotels, hospitals, civil air defense, mines and other industries, and can be used to discharge sewage, waste water, rainwater and urban domestic water with solid particles and various long fibers.

250KW 280KW 315KW Sewage Pump For Mine Or Hospita Conditions of use:

1. The temperature of the medium should not exceed 60°C, the density of the medium should not exceed 1200Kg/m3, and the pH value should be within the range of 5-9.

2. The pump must not be lower than the minimum liquid level during operation, see "minimum liquid level" (including automatic cooling system) in the installation dimension drawing. If there is no automatic cooling system, the minimum liquid level during operation shall not be lower than 2/3 of the total height of the pump.

3. The rated voltage is 380V and the rated frequency is 50HZ. The motor can run normally only when the deviation between rated voltage and rated frequency is not more than ±5%.

4. The maximum diameter of solid particles passing through the pump shall not be greater than 5% of the diameter of the discharge port of the pump body.

5. Seen from the suction port of the pump, the impeller rotates counterclockwise.

Repair and maintenance of 250KW 280KW 315KW Sewage Pump For Mine Or Hospital:

1. The electric pump should be managed and used by special personnel, and regularly check whether the insulation resistance between the electric pump winding and the casing is normal.

2. After each use, especially for thicker and viscous slurries, the electric pump should be put into clean water and run for several minutes to prevent deposits from remaining in the pump and ensure the cleanliness of the electric pump.

3. If the electric pump is not used for a long time, the electric pump should be taken out of the water and not soaked in water for a long time, so as to reduce the chance of the stator winding of the motor getting wet and increase the service life of the electric pump.

4. Under normal conditions, the oil in the oil chamber should be filled or replaced after every 300-500 hours of use of the pump (No. 10-30 engine oil), so as to keep the mechanical seal in a good lubricating state and improve the service life of the mechanical seal.

5. After the electric pump is disassembled and repaired, the casing components must be checked by a 0.2MPa airtight test to ensure reliable sealing of the motor.

6. The seal ring between the impeller and the pump body has a sealing function. If the seal is damaged, it will directly affect the performance of the pump and should be replaced if necessary.

Model of 250KW 280KW 315KW Sewage Pump For Mine Or Hospital:

    Zhengzhou Shenlong Pump Industry CO.,Ltd, a professional reputable ODM OEM water pump manufacturer in China since 1996, recognized by CE and ISO, ABS, SGS, BV.

  Main products: Electric Submersible Pump for pumping clean water, hot water and sea water with bronze, SS304, SS316, SS316L, Dupex stainless/SS904L; Mine Submersible Pump/Submersible Motor/Sewage Submersible Pump/Slurry Submersible Pump/Fountain Submersible Pump/Axail Flow Submersible Pump/Surface Centrifugal Water Pump. Related business: kinds of water pipes, cables, control panels, inverter and other pump spare parts.

   Over 70 countries’ customers are enjoying our pumps and service. Our pumps are widely used in fields, such as seawater aquaculture & desalination, offshore, jack-up, floating dock, shipyard, irrigation, wastewater treatment, fountain projects. We are seeking for local water pump service business and dealer who is professional in water pumps. Welcome to join us.

    Zhengzhou Shenlong Pump Industry CO.,Ltd has three complete casting lines, including Expendable casting process, wax casting mold, coated sand, it can meets the different requirements on the dimensional accuracy of casting. The wax casting mold line, special for stainless steel material, was finished in the thermostatic workshop to guarantee the casting accuracy, meanwhile, shorten the whole production time.

  More than 85 sets production machine, includes grinding machine, CNC, lathe, Milling, High speed punch press machine, testing machine, etc., with sufficient spare parts stock to guarantee the production capacity 11,000 sets per month. From material purchase, metalworking, impeller dynamic balance, motor winding, insulation and pump assembling, passed more than 27 inspection processes, to ensure the quality meet a criterion.
